SEMCO® Proximity Sensor Part #235184 — Pneumatic · For T-Slot · Block Design | Magnetic Measuring Principle | 3/2-Way Valve Normally Closed | M5 Internal Thread | 2–8 Bar | IP65 | Visual Switching Status Indication | RoHS Compliant · Copper & PTFE Free The SEMCO® Proximity Sensor Part #235184 is a pneumatic proximity switch with magnetic measuring principle — engineered for T-slot in block design. Features a 3/2-way valve (normally closed) with M5 internal thread pneumatic connection — delivering precise, reliable switching performance across demanding industrial environments.

Designed for drives with T-slot — the Part #235184 proximity sensor operates on a magnetic measuring principle for accurate, consistent switching performance. The 3/2-way valve function (normally closed) with M5 pneumatic connection delivers ±0.2mm reproducibility of switching value. IP65 protection class — visual optical switching status indication — RoHS compliant and free of copper and PTFE. Note: separate mounting component required — insertable in slot from above with accessories.

🧲

Magnetic Measuring Principle | 3/2-Way Valve Normally Closed | M5 Internal Thread | 2–8 Bar Working Pressure | ±0.2mm Reproducibility | Switch-On 22ms · Switch-Off 52ms | IP65 | 11g Product Weight The magnetic measuring principle ensures accurate, repeatable switching performance with ±0.2mm reproducibility of switching value. Operating at 2–8 bar working pressure — switch-on time 22ms · switch-off time 52ms. IP65 protection class — product weight 11g.

🧲 Magnetic Measuring Principle Accurate repeatable switching — ±0.2mm reproducibility

🔀 3/2-Way Valve Normally Closed M5 internal thread — pneumatic connection, reliable function

💨 2–8 Bar Working Pressure Compressed air ISO8573-1:2010 Class 6-4-4 — non-lubricated

🛡️ IP65 Protection Class Dust-tight · water-resistant — industrial environments

👁️ Visual Display Optical Status Switching status indication — easy monitoring, instant feedback

✅ RoHS Compliant Copper & PTFE free — environmentally compliant design

🧲

Magnetic Measuring Principle — Accurate Consistent Switching | ±0.2mm Reproducibility of Switching Value | Switch-On 22ms · Switch-Off 52ms | T-Slot Block Design The magnetic measuring principle delivers accurate, consistent switching performance with a reproducibility of switching value of ±0.2mm. Engineered for T-slot in block design — switch-on time 22ms · switch-off time 52ms — ensuring fast, reliable response in demanding pneumatic applications.

🔀

3/2-Way Valve — Normally Closed | M5 Internal Thread Pneumatic Connection | 2–8 Bar Working Pressure | Compressed Air ISO8573-1:2010 Class 6-4-4 🔀 3/2-Way Valve Normally closed — reliable valve function, precise pneumatic control 🔩 M5 Internal Thread Pneumatic connection — compact, secure, industry-standard M5 port 💨 2–8 Bar Working pressure — compressed air ISO8573-1:2010 Class 6-4-4, non-lubricated

💨

Operating Medium — Compressed Air ISO8573-1:2010 Class 6-4-4 | Non-Lubricated Operation | 2–8 Bar Working Pressure | -15°C to 60°C Ambient Temperature Operating medium: compressed air in accordance with ISO8573-1:2010 Class 6-4-4. Lubricated operation not possible — ensure non-lubricated compressed air supply. Ambient temperature range: -15°C to 60°C. Working pressure: 2–8 bar.

🔧

Mounting Type — With Through Hole | Insertable in Slot from Above · With Accessories | For Drives with T-Slot | Separate Mounting Component Required 🔲 T-Slot Design For drives with T-slot — precise positioning, secure fit, block design ⬆️ Insertable from Above Insertable in slot from above with accessories — easy installation, secure mounting ⚠️ Separate Mounting Kit Separate mounting component required — not included, order separately

🏗️

Housing Materials — Aluminum (Anodized) · PA · High Alloy Steel Non-Corrosive | Durable Industrial-Grade Construction | Product Weight 11g 🔩 Aluminum Anodized — lightweight, corrosion-resistant housing 🧱 PA Polyamide — durable, impact-resistant component material ⚙️ High Alloy Steel Non-corrosive — high-strength, long-lasting performance ⚖️ 11g Product weight — compact lightweight design

🛡️

IP65 Protection Class — Dust-Tight · Water-Resistant | Visual Optical Switching Status Indication | Easy Monitoring — Instant Feedback IP65 protection class — dust-tight and water-resistant for reliable operation in demanding industrial environments. Visual optical switching status indication provides instant, easy-to-read feedback on the current switching state — enabling fast diagnostics and monitoring without additional instrumentation.

✅

RoHS Compliant — Environmentally Responsible Design | Free of Copper & PTFE | Meets International Environmental Standards Conforms to RoHS — meeting international environmental and hazardous substance standards. Free of copper and PTFE — ensuring material compatibility and compliance across regulated industries and applications.

SEMCO® Proximity Sensor Part #235184 | Pneumatic · For T-Slot · Block Design | Magnetic Measuring Principle | 3/2-Way Valve Normally Closed | M5 Internal Thread | 2–8 Bar | ±0.2mm Reproducibility | Switch-On 22ms · Switch-Off 52ms | IP65 | Visual Optical Status Indication | Aluminum Anodized · PA · High Alloy Steel | RoHS Compliant · Copper & PTFE Free | -15°C to 60°C | 11g | Separate Mounting Component Required

SEMCO® Proximity Sensor Part #235184 — pneumatic proximity switch with magnetic measuring principle for T-slot in block design. 3/2-way valve (normally closed) with M5 internal thread pneumatic connection — 2–8 bar working pressure — ±0.2mm reproducibility of switching value — switch-on 22ms · switch-off 52ms. IP65 protection class — visual optical switching status indication. Aluminum (anodized) · PA · high alloy steel (non-corrosive) housing — RoHS compliant · free of copper and PTFE — -15°C to 60°C ambient temperature — 11g product weight. Separate mounting component required — insertable in slot from above with accessories.

🧲 Magnetic — ±0.2mm Reproducibility · Accurate Switching | 🔀 3/2-Way Normally Closed — M5 Internal Thread | 💨 2–8 Bar — ISO8573-1:2010 Class 6-4-4 · Non-Lubricated | 🛡️ IP65 — Dust-Tight · Water-Resistant | 👁️ Visual Status — Optical Indication · Instant Feedback | ✅ RoHS — Copper & PTFE Free | 🌡️ -15–60°C — Wide Ambient Range | ⚖️ 11g — Compact Lightweight | 🔧 T-Slot — Insertable from Above · Separate Mounting Required | 🏗️ Aluminum Anodized · PA · High Alloy Steel

Legal Notice: All recommendations, statements, and technical data contained herein are based on tests believed to be reliable and correct, but accuracy and completeness are not guaranteed and are not to be construed as a warranty, either expressed or implied. User shall rely on their own information and tests to determine suitability of the product for the intended use and assumes all risks and liability resulting from use of the product.

Usage Notice: The SEMCO® Proximity Sensor Part #235184 (pneumatic · for T-slot · block design · magnetic measuring principle · 3/2-way valve normally closed · M5 internal thread · 2–8 bar · IP65 · 11g) is designed for pneumatic proximity sensing in T-slot drives — verify suitability for your specific drive configuration and application requirements before use. This sensor requires a separate mounting component — the mounting kit is not included; order the appropriate mounting accessory separately before installation. Operating medium must be compressed air in accordance with ISO8573-1:2010 Class 6-4-4 — lubricated operation is not possible; ensure your compressed air supply is non-lubricated and meets the specified quality standard before connecting. Verify that your system working pressure is within the specified 2–8 bar range before operation — operating outside this range may result in malfunction or damage. Ambient temperature must remain within -15°C to 60°C during operation — verify installation environment temperature compliance before use. The IP65 protection class provides dust-tight and water-resistant protection — verify that the installation environment and connection points maintain IP65 integrity after installation. The visual optical switching status indication is provided for monitoring convenience — do not rely solely on the visual indicator for safety-critical switching confirmation; verify switching performance with appropriate instrumentation for your application. Conforms to RoHS and is free of copper and PTFE — verify material compatibility with your specific application media and environment before use. Always follow applicable safety guidelines, pneumatic system standards, and industry regulations for your specific installation and operating environment. Specifications subject to change without notice. Data sheet reference: Part #235184 · 08/07/2018 · SEMCO®.
